Dimensions
Boom/Stick Option (HEX) 1
Shipping Length of Unit
21.17 ft in
Shipping Height of Unit
8.34 ft in
Max Loading Height
17.23 ft in
Max Reach Along Ground
23.53 ft in
Max Vertical Wall Digging Depth
12.64 ft in
Max Digging Depth
15.1 ft in

Dimensions
Width to Outside of Tracks
7.22 ft in
Length of Track on Ground
9.52 ft in
Ground Clearance
1.28 ft in
Tail Swing Radius
4.79 ft in

Undercarriage
Shoe Size
17.72 in

Specifications
Engine
Number of Cylinders
4
Engine Make
2334
Engine Model
V3800-DI
Gross Power
64.2 hp
Power Measured @
2000 rpm
Displacement
231.9 cu in

Operational
Operating Weight
18364.6 lb
Hydraulic System Relief Valve Pressure
4061.1 psi
Hydraulic Pump Flow Capacity
38.1 gal/min

Undercarriage
Shoe Size
17.8 in
Max Travel Speed
3.2 mph
Buckets
Reference Bucket Capacity
0.4 yd3
Boom/Stick Option (HEX) 1
Shipping Height of Unit
8.4 ft in
Shipping Length of Unit
21.2 ft in
Max Digging Depth
15.1 ft in
Max Reach Along Ground
23.6 ft in
Max Loading Height
17.3 ft in
Max Vertical Wall Digging Depth
12.7 ft in

Dimensions
Width to Outside of Tracks
7.3 ft in
Ground Clearance
1.3 ft in
Tail Swing Radius
4.8 ft in
Length of Track on Ground
9.6 ft in



Spec Source: https://www.ritchiespecs.com/model/kubota-kx080-3-midi-excavator
